Model : BY-AM-FM-07

Product Overview
Frequency: 76-110MHz (FM), 525-1,700MHz (AM)
Gain: 2
Antenna length(mm):350
Screw:M8





 Model : BY-330/340M-04

 Frequency(MHz ):330~340
VSWR ≤1.5
Gain(dBi):2
Polarization:Vertical
Radiation:Omni
Power(W):50
Input Impedance(Ω):50
Antenna Length(mm):93











Model : BY-LTE-0207

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.0
Gain(dBi):5
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna size(mm):232x47x8.5
Connector:SMA/FME/TNC etc.
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃









Model : BY-LTE-0208

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤1.5
Gain(dBi):5
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):161
Connector:SMA
Storage Temperature:-30 ℃ to+75℃
Operating Temperature:-30℃ to+75℃













Model:BY-LTE-02-11

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤2
Gain(dBi):6
Max Input power(W):60
Input Impedance(Ω):50
Polarization:Vertical
Size(mm):Φ62×235

Antenna Bracket(mm):120*75

Cable Length(m):2,3,5 etc.
Cable Type:RG174
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Housing:white
Storage Temperature:-45℃ to+75℃



 Model:BY-LTE-02-12

Frequency(MHz):698-960/1710-2170/2500-2700

VSWR ≤2
Gain(dBi):9
Max Input power(W):60
Input Impedance(Ω):50
Polarization:Vertical
Base Size(mm):Φ90

Antenna length(mm):260

Cable Length(m):2,3,5 etc.
Cable Type:RG174
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Storage Temperature:-45℃ to+75℃
Operating Temperature:-45℃ to+75℃











Model:BY-LTE-0209

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.0
Gain(dBi):5
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):360
Connector:SMA
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃





 Model : BY-LTE-02-10

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.0
Gain(dBi):3
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna size(mm):
Φ40X80

Antenna Bracket:50*40*40

Cable Length(m):2,3,5 etc.
Cable Type:RG174
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃









Model : BY-433-385MM

Frequency(MHz):449MHZ,88~108MHZ,174~214MHZ
VSWR:1:1.5
Gain(dBi):3
Polarization:Vertical
Radiation:Omni
Power(W):50
Input Impedance(Ω):50
Antenna Length(mm):385
Connector:SMA.









Model : BY-433-08-01

Frequency(MHz):433±5
VSWR ≤2.5
Gain(dBi):2
Max Input power(W):60
Input Impedance(Ω):50
Polarization:Vertical
Size(mm):Φ30×81(Height)
Cable Length(m):2,3,5 etc.
Cable Type:RG174 /RG316
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting:Screw
Housing:Black / grey
Storage Temperature:-45℃ to+75℃
Operating Temperature:-45℃ to+75℃





Model :BY-433-11-02

Frequency (MHz):434MHz±5
VSWR: ≤1.5
Gain(dBi):3
Max Input power(W):60
Input Impedance(Ω):50
Polarization :Vertical
Antenna Length(mm):200
Cable Length(m):2.3.5etc.
Cable Type:RG174
Connector :SMA/SMB/SMC/BNC/FAKRA/FME etc.
Mounting :Screw (Hole/Roof)
Housing:Black
Storage Temperature:-45℃ to+75℃
Operating Temperature :-45℃ to+75℃







Model : BY-868-915-FPCB

Frequency(MHz ):868~915
VSWR :1.2
Gain(dBi):2
Power(W):50
Input Impedance(Ω):50
Size(mm):79X10
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta


Model:BY-868-05-01

Frequency(MHz):868
VSWR ≤2
Gain(dBi):3
Max Input power(W):60
Input Impedance(Ω):50
Polarization:Vertical
Size(mm):120X13X5
Cable Length(m):2,3,5 etc.
Cable Type:RG174 /RG178/RG316
Connector :SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting :Adhesive



Model : BY-868-05-03

Frequency(MHz):858-878
Bandwidth(MHz):20
VSWR ≤ 2
Gain(dBi):3
Max Input power(W):50
Input Impedance(Ω):50

Polarization:Vertical
Size(mm):143.7 ×24×11.5
Cable Length(m):2,3,5 etc.
Cable Type:RG174
Connector :SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting :Adhesive,Screw

Working Temp:-40℃~+85℃
Storage Temp:-45℃~+100℃

Weatherproof:IP68


Model:BY-915-Flex-Whip

Frequency(MHz):902-928
VSWR ≤2
Gain(dBi):3
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):177
Connector:SMA( Straight )
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃





Model : BY-GSM-11-02

Frequency (MHz):850-1900/900-1800
Bandwidth(MHz):90/280
VSWR:1:1.5
Gain(dBi):3
Max Input power(W):60
Input Impedance(Ω):50
Polarization :Vertical
Antenna Length(mm):200
Cable Length(m):2.5,3 etc.
Cable Type:RG174
Connector :SMA/SMB/SMC/BNC/FAKRA/FME etc.
Mounting :Screw (Hole/Roof)
Housing:Black
Storage Temperature:-45℃ to+75℃
Operating Temperature :-45℃ to+75℃

Model:BY-GPS-11
(i)Dielectric Antenna
Center Frequency(MHz):1575.42±2
VSWR:1.5:1
Bandwidth(MHz):±5
Impedance(Ω):50
Peak Gain >3dBi Based on 7cm×7cm ground plane
Gain Coverage >-4dBi at –90°<0 <+90°(over 75% Volume)
Polarization:RHCP
(ii)LNA/Filter
LNA Gain (Without cable) :30 dBi Typical
Noise Figure(dB):2.0
Filter Out Band Attenuation (f0=1575.42 MHz) :40dB Min f0+/-50MHz ;
VSWR <2.0
DC Voltage(V):2.7 to 5.5v
DC Current(mA):11 Max
(iii)Mechanical
Weight(gram )<110
Size(mm):50.3X50.3X15.5
Cable Length(m):2,3 etc.
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting:Magnetic/adhesive
Housing:Black
(iv)Environmental
Working Temp:-40℃~+85℃
Storage Temp:-45℃~+100℃
Vibration:Sine sweep 1g(0-p)10~50~10Hz each axis
Humidity:Humidity95%~100%RH
Weatherproof:100%Waterproof


Model:BY-GPS-99-1

Frequency(MHz):1575.42 MHz±5MHz
VSWR ≤1:1.5
Gain(dBi):2.15
Max Input power(W):20
Input Impedance(Ω):50
Polarization:Vertical
Size:Φ18X37(Height) mm
Connector:SMA
Housing:Black
Storage Temperature:-45℃to+75℃
Operating Temperature:-45℃to+75℃



 Model : BY-GPS-11-01

Dielectric Antenna
Center Frequency(MHz):1575.42±2
VSWR:1.5:1
Bandwidth(MHz):±5
Impedance(Ω):50
Peak Gain >3dBi Based on 7cm×7cm ground plane
Gain Coverage >-4dBi at –90°<0 <+90°(over 75% Volume)
Polarization:RHCP

(ii)LNA/Filter
LNA Gain (Without cable) :32dBi Typical
Noise Figure(dB):2.0
Filter Out Band Attenuation (f0=1575.42 MHz) :40dB Min f0+/-50MHz ;
VSWR <2.0
DC Voltage(V):2.7 to 5.5v
DC Current(mA):11 Max
(iii)Mechanical
                                                                                                  Weight(gram )<110
                                                                                                  Size(mm):61X61X18
                                                                                                  Cable Length(m):2,3 etc.
                                                                                                  Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX
                                                                                                  Mounting:Magnetic/adhesive
                                                                                                  Housing:Black
                                                                                                (iv)Environmental
                                                                                                  Working Temp:-40℃~+85℃
                                                                                                  Storage Temp:-45℃~+100℃
                                                                                                  Vibration:Sine sweep 1g(0-p)10~50~10Hz each axis
                                                                                                  Humidity:Humidity95%~100%RH
                                                                                                  Weatherproof:100%Waterproof


Moder:BY-GPS-99

Frequency(MHz):1575.42 MHz±5MHz
VSWR ≤1:1.5
Gain(dBi):2.15
Max Input power(W):20
Input Impedance(Ω):50
Polarization:Vertical
Size:Φ11 ×49(Height) mm
Connector:SMA
Housing:Black
Storage Temperature:-45℃to+75℃
Operating Temperature:-45℃to+75℃


Model:BY-2.4/5.8G-02

Frequency(MHz ):2400~2500,5150~5850
VSWR :1.2
Gain(dBi):3
Power(W):50
Input Impedance(Ω):50
Size(mm):51X9X0.5
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta







Model:BY-2.4/5.8G-X3

Frequency(GHZ ):2.4~2.5/5.1~5.9
VSWR :1.2
Gain(dBi):2
Power(W):20
Input Impedance(Ω):50
Size(mm):Φ15 ×19(Height)
Cable Length(mm):5-300

Cable Type:RG174
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.









Model : BY-2.4/5.8G-03

Frequency(MHz ):2400~2500,5150~5850
VSWR :1.2
Gain(dBi):3
Power(W):50
Input Impedance(Ω):50
Size(mm):3X8X0.5
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta






Model:BY-2.4/5.8G-04

Frequency(MHz ):2400~2500,5150~5850
VSWR :1.2
Gain(dBi):5
Power(W):50
Input Impedance(Ω):50
Antenna Length(mm):157
Connector:SMA
Radiation Pattern:Omni directional
Polarization:Horizonta





Model: BY-2400-01-09

Frequency(MHz ):2400-2500
VSWR :1.2
Gain(dBi):3
Return Loss(dBi):-21.21
Power(W):50
Input Impedance(Ω):50
Size(mm):70X20 X 0.8
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta





Model: BY-2400-01-10

Frequency(MHz ):2400-2500
VSWR :1.2
Gain(dBi):3
Return Loss(dBi):-21.21
Power(W):50
Input Impedance(Ω):50
Size(mm):54X14X0.8
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta





Model : BY-2400-01-FPCB

 Frequency(MHz ):2400-2500
VSWR :1.2
Gain(dBi):3
Return Loss(dBi):-21.21
Power(W):50
Input Impedance(Ω):50
Size(mm):54X36X0.1
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional


Model:BY-2400-02-04

FrequencyMHz):2400-2500
VSWR ≤1.5
Gain
dBi:5
Max Input power
W):50
Input Impedance
Ω):50
Polarization
Vertical
Antenna Length
mm):196
Cable Length
mm):50-200
Connector
H.FL/U.FL/IPEX/GSC/MCG etc.
Storage Temperature
-30  to+75
Operating Temperature
-30 to+75





Model :BY-2400-02-FPCB

 Frequency(MHz ):2400-2500
VSWR :1.2
Gain(dBi):3
Return Loss(dBi):-21.21
Power(W):50
Input Impedance(Ω):50
Size(mm):48X32X0.1
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta





Model:BY-2400-03-FPCB

Frequency(MHz ):2400-2500
VSWR :1.2
Gain(dBi):3
Return Loss(dBi):-21.21
Power(W):50
Input Impedance(Ω):50
Size(mm):36X30X0.1
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta


Model:BY-2400-04-FPCB

Frequency(MHz ):2400-2500
VSWR :1.2
Gain(dBi):3
Return Loss(dBi):-21.21
Power(W):50
Input Impedance(Ω):50
Size(mm):28X14X0.1
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta





Model: BY-2400-03-01

Frequency(MHz):2400-2500
VSWR ≤1.5
Gain(dBi):2
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Size(mm):Φ18×47
Cable Length(m):2,3,5 etc.
Cable Type:RG174
Connector:SMA/SMB/BNC/FME/TNC etc.
Mounting:Screw
Housing:Black
Storage Temperature:-45℃ to+75℃
Operating Temperature :-45℃ to+75℃







Model : BY-2400-06

Frequency(MHz):2400-2500
VSWR≤1.5
Gain(dBi):5
Return Loss(dBi):17
Power(W):50
Input Impedance(Ω):50
Antenna Length(mm):175
Connector:N Straight Male







Model : BY-2400-7dbi

FrequencyMHz):2400-2500
VSWR ≤1.5
Gain(dBi):7

Return Loss(dBi):17
Power(W):50
Input Impedance(Ω):50
Antenna Length(mm):265
Connector:SMA/TNC/FME









Model : BY-3G-01-01

Frequency(MHz):850/900/1800/1900/2100
Bandwidth(MHz):70/180
VSWR ≤ 2
Gain(dBi):2
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):46
Connector:TS9/CRC9
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃



Model : BY-2400-08-01

Frequency(MHz):2400-2500
VSWR ≤2.5
Gain(dBi):2
Max Input power(W):60
Input Impedance(Ω):50
Polarization:Vertical
Size(mm):Φ30×81(Height)
Cable Length(m):2,3,5 etc.
Cable Type:RG174 /RG316
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting:Screw
Housing:Black / grey
Storage Temperature:-45℃ to+75℃
Operating Temperature:-45℃ to+75℃

Model : BY-3G-05-03

Frequency(MHz):850/900/1800/1900/2100

Bandwidth(MHz):20
VSWR ≤ 2
Gain(dBi):3
Max Input power(W):50
Input Impedance(Ω):50

Polarization:Vertical
Size(mm):143.7 ×24×11.5
Cable Length(m):2,3,5 etc.
Cable Type:RG174
Connector :SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting :Adhesive,Screw

Working Temp:-40℃~+85℃
Storage Temp:-45℃~+100℃

Weatherproof:IP68


Model:BY-3G-01-02

FrequencyMHz):850/900/1800/1900/2100
Bandwidth
MHz):70/180
VSWR ≤ 2
Gain
dBi):3
Max Input power
W):50
Input Impedance
Ω):50
Polarization
Vertical
Antenna Length
mm):148
Connector
锚点SMA/FME/TNC etc.
Storage Temperature-30 to+75
Operating Temperature
-30 to+75

Model:BY-3G-13-01

Frequency(MHz):850/900/1800/1900/2100
Bandwidth(MHz):70/180
VSWR ≤ 2
Gain(dBi):2
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Size(mm):Φ37×82
Cable Length (cm):2,3 etc.

Cable Type:RG174
Connector:SMA/SMB/SMC/BNC/FAKRA/FME etc.
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃



Model : BY-3G-11-02

Frequency (MHz):850/900/1800/1900/2100
VSWR: ≤1.5
Gain(dBi):3
Max Input power(W):60
Input Impedance(Ω):50
Polarization :Vertical
Antenna Length(mm):200
Cable Length(m):2.3.5etc.
Cable Type:RG174
Connector :SMA/SMB/SMC/BNC/FAKRA/FME etc.
Mounting :Screw (Hole/Roof)
Housing:Black
Storage Temperature:-45℃ to+75℃
Operating Temperature :-45℃ to+75℃


Model:BY-LTE-FPCB-01

Frequency(MHz ):698-960/1710-2170/2500-2700
VSWR :1.2
Gain(dBi):3
Power(W):50
Input Impedance(Ω):50
Size(mm):89X19X0.1
Cable Length(mm):50-200
Connector:H.FL/IPEX/GSC etc.
Radiation Pattern:Omni directional
Polarization:Horizonta


Model:BY-LTE-01-01

FrequencyMHz ):698-960/1710-2170/2500-2700
VSWR :1.2
Gain
dBi):3
Power
W):50
Input Impedance
Ω):50
Size
mm):75X20X0.5
Cable Length(mm)
50-200
Connector
H.FL/IPEX/GSC etc.
Radiation Pattern
Omni directional
Polarization
Horizonta


Model:BY-LTE-FPCB-02

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤3
Gain(dBi):3
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Size(mm):64X16X0.1

Cable Length(mm):50-200
Connector:H.FL/U.FL/IPEX/GSC/MCG etc.
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃


Model:BY-LTE-02-03

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.0
Gain(dBi):5
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):195X38
Connector:SMA/TNC etc.
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃







Model:BY-LTE-02-04

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤1.5
Gain(dBi):5
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):196
Cable Length(cm):5-20
Connector:H.FL/U.FL/IPEX/GSC/MCG etc.
Storage Temperature:-30 ℃ to+75℃
Operating Temperature:-30℃ to+75℃





Model : BY-LTE-02-05

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.0
Gain(dBi):4
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):192X16
Connector:SMA
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃


Model:BY-LTE-02-06

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.0
Gain(dBi):4
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):192X16
Connector:SMA
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃


Model:BY-LTE-08-01

Frequency(MHz):824-960-1710-2700
VSWR ≤2.5
Gain(dBi):2
Max Input power(W):60
Input Impedance(Ω):50
Polarization:Vertical
Size(mm):Φ30×81(Height)
Cable Length(m):2,3,5 etc.
Cable Type:RG174 /RG316
Connector:SMA/SMB/SMC/BNC/FME/TNC/MCX/MMCX etc.
Mounting:Screw
Housing: Grey /Black
Storage Temperature:-45℃ to+75℃
Operating Temperature:-45℃ to+75℃





Model : BY-5800-03-01

 Frequency(MHz):5725-5850
VSWR ≤1.5
Gain(dBi):2
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Size(mm):Φ18×47
Cable Length(m):2,3,5 etc.
Cable Type:RG174
Connector:SMA/SMB/BNC/FME/TNC etc.
Mounting:Screw
Housing:Black
Storage Temperature:-45℃ to+75℃
Operating Temperature :-45℃ to+75℃


Model:BY-LTE-07-01

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.5
Gain(dBi):3
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):168
Connector: SMA Rotation male 、
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃


Model:BY-5800-04

Frequency(MHz):5750~5850
Bandwidth(MHz):100
VSWR ≤1.5
Gain(dBi):3
Polarization:Vertical
Power(W):50
Input Impedance(Ω):50
Size:(mm):76.5X35
Connector:SMA

Cable:RG141


Model:BY-LTE-07-02

Frequency(MHz):698-960/1710-2170/2500-2700
VSWR ≤ 2.5
Gain(dBi):3
Max Input power(W):50
Input Impedance(Ω):50
Polarization:Vertical
Antenna Length(mm):220
Connector: SMA Rotation male 、
Storage Temperature:-30℃ to+75℃
Operating Temperature:-30℃ to+75℃


Model:BY-5800-05

Frequency(MHz):5645-5945
Bandwidth(MHz):100
VSWR ≤1.5
Gain(dBi):3
Polarization:Vertical
Power(W):50
Input Impedance(Ω):50
Size:(mm):90X33
Connector:SMA

Cable:RG141





Model: BY-5800-06

 Frequency(MHz):5645-5945
Bandwidth(MHz):100
VSWR ≤1.5
Gain(dBi):3
Polarization:Vertical
Power(W):50
Input Impedance(Ω):50
Size:(mm):76X40
Connector:SMA

Cable:RG141



Model:BY-5800-07

 Frequency(MHz):5645-5945
Bandwidth(MHz):100
VSWR ≤1.5
Gain(dBi):3
Polarization:Vertical
Power(W):50
Input Impedance(Ω):50
Size:(mm):85X36
Connector:SMA
Cable:RG141





 Model : BY-5800-08

Frequency(MHz):5725-5850
VSWR≤1.5
Gain(dBi):5
Return Loss(dBi):17
Power(W):50
Input Impedance(Ω):50
Antenna Length(mm):175
Connector:N Straight Male





 Model:BY-SRCA-1

 Semi-Rigid cable has a solid outer conductor which is typically made from copper. Solid metal outer sheath provides better shielding function and fixes dielectric and center conducter. Thus, it allows electrical stable comparing to flexible cable. HLT provide bending solution to customers. Precision bending maintain the concentricity of cable and keep signal transimission.
Application: test and measurement devices , military and defense, high bandwidth equipment...


Cable type: .047 / .086 / .141

Connector: SMA straight male,SMA right angle male,SMA straight female,N male ect

Cable Length(cm):8,10 etc.







RF Adaptor Connectors

BY-SMA Male to N female

BY-SMA female to N male













MODEL:BY-SRCA-2

Semi-Rigid cable has a solid outer conductor which is typically made from copper. Solid metal outer sheath provides better shielding function and fixes dielectric and center conducter. Thus, it allows electrical stable comparing to flexible cable. HLT provide bending solution to customers. Precision bending maintain the concentricity of cable and keep signal transimission.
Application: test and measurement devices , military and defense, high bandwidth equipment...

Connector:SMA Straight Female Bulkhead to stripped end
Cable Length(cm):8,10 etc.
Cable Type:047 / .086 / .141





MODEL:BY-FCA-1

The flexibility of conformable cable is between flexible cable and semi-rigid cable. As its name implies, it can be formed by hand without bending tool. Such characteristic make it easy-to-adjust for customers


Application: test and measurement devices
Cable type: 047 / 086 / 141 / LL series /  LMR series...

Connector: SMA straight male,SMA right angle male,SMA straight female,N male ect

Cable Length(cm):8,10 etc.









Model : BY-CLSP-SS-3G

VSWR: ≤1.2

Insertion loss: ≤0.25db

Frequency(Mhz): DC-3GHZ

Max Input power:20kw

Connector:SMA-K to SMA-J

Working temper ature: -45℃~+80℃

Waterproof level: IP67

Ground wire diameter: ≥16㎡

The response time: < 50 NS

The residual voltage: < 0.2V

Size(mm):48.5 length
